Coiled Air Hose Assemblies
HYDRAULIC HOSE
.com ®

Hose Assemblies
Recommended for use with pnuematic
tools. Lightweight, self-retracting
hose coil eliminates the need for reels
and other expensive take-up devices.
Available in yellow only.
• 200 psi max. working pressure at 78° F
• 800 psi minimum burst
• NPTF male pipe fi ttings
(one end swivels)
Caution: Do not use in applications
where temperature exceeds 200° F.
Higher temperatures could result in
hose rupture.
Item # Size Max. Working Length Price
313004-J12 1/4" 10½ feet
313004-J25 1/4 23½ feet
313004-J50 1/4" 47 feet
313004-J100 1/4" 94 feet

Threaded Sleeve

36100 36200 36300 36400
Nut Male Connector Union Male Elbow

(1) tube, (2) NPT male (1) tube, (2) tube
36100-02
(1) tube, (2) NPT male
36100-03 36200-02-02 36300-04-04
36100-04 36200-03-02 36400-02-02
36100-05 36200-04-02 36400-03-02
36100-06 36200-05-02 36400-04-02
36200-06-04 36400-05-02

Double compression • Use with
aluminum and copper tubing
