Page 64 - DHH Catalog

NPSM • Female Pipe Swivels HYDRAULIC HOSE
.com ®

1503 1504 1602 459
Male Pipe x Female Pipe Female Pipe x Female Pipe Female Pipe x Female Pipe Seal Nut for Male Pipe
Swivel 45° Elbow Swivel 45° Elbow Swivel Branch Tee

459-02
459-04
(1) NPTF male, (2) NPSM swivel (1) NPTF female, (2) NPSM swivel
(1) NPTF female, (2) NPSM 459-06
SAE# 140330 SAE# 140331
swivel, (3) NPSM swivel
Aeroquip 2049 (Reversed) 459-08
Aeroquip 2050 (Reversed)
Parker 3107 Aeroquip 2253 (Reversed) 459-12
Weatherhead 9355 (Reversed)
1504-02-02 1602-02-02-02 459-16
1503-02-02 1504-04-04 1602-04-04-04 459-32
1503-02-04 1504-04-06 1602-06-04-04
1503-04-02 1504-06-04 1602-06-06-06 PTFE Thread Sealant
1503-04-04 1504-06-06 1602-08-06-06
1503-04-06 1504-08-06 1602-08-08-08
1503-06-04 1504-08-08 1602-12-08-08
1503-06-06 1504-12-08 1602-12-12-12
1503-06-08 1504-12-12 1602-16-12-12
1503-08-04 1504-16-12 1602-16-16-16
1503-08-06 1504-16-16 1602-20-20-20
1503-08-08 1504-20-20 Temp. range: -50° to 500° F
1503-08-12 1504-24-24 1603
1503-12-06 Female Pipe Swivel Tee LCTS14 (1/4 pint)
1503-12-08 1601 LCTS1 (1/2 pint)
1503-12-12 Male Pipe x Female Pipe LCTS2 (1 pint)
1503-12-16 Swivel Branch Tee
1503-16-12
1503-16-16
1503-16-20
1503-20-16
(1–3) NPSM swivel
1503-20-20
1503-24-24 1603-02-02-02
(1) NPTF male, (2) NPSM swivel,
1503-32-32 1603-04-04-04
(3) NPSM swivel
1603-06-06-06
Aeroquip 2254 (Reversed)
PTFE Thread Sealing Tape 1603-08-08-08
1601-02-02-02 1603-12-12-12
1601-04-04-04 1603-16-16-16
1601-04-06-06 1603-20-20-20
1601-06-04-04
1601-06-06-06
1/2" wide. Meets military 1601-08-04-04
specification MIL-T-27730A
1601-08-06-06
TTA50 (260" roll) 1601-08-08-08
TTB50 (520" roll) 1601-12-08-08
1601-12-12-12
1601-12-16-16
1601-16-12-12
1601-16-16-16
1601-20-20-20
1601-24-24-24

Page 62 800-535-1302 • SAVE 6% WHEN YOU BUY ONLINE at www.DiscountHydraulicHose.com ST2003
