Page 53 - British and Metric Catalog

Carbon Steel Carbon Steel
HYDRAULIC HOSE
.com ®
.com ® HYDRAULIC HOSE
9605S 9606 (Continued) 9607 9635S
Male JIC x Male Metric Dual Purpose Male Pipe (NPTF) x Male Metric Dual Purpose Male Metric Dual Purpose x Female Pipe (NPTF)
Port or light series tube (DIN 2353 L) 9606-08-S12-20 #8 12 mm M20x1.5 Port or tube (DIN 2353 L light series or DIN 2353 S heavy series) Port or tube (DIN 2353 L light series or DIN 2353 S heavy series)
Includes washer and O-ring 9606-08-S14-22 #8 14 mm M22x1.5 1. Male pipe (NPTF) Includes washer and O-ring
9606-08-S16-24 #8 16 mm M24x1.5
1. Male JIC 37° 9606-10-S12-20 #8 12 mm M20x1.5 2. Nominal tube O.D. 1. Male metric thread
2. Nominal tube O.D. 3. Male metric thread 2. Nominal tube O.D.
3. Male metric thread 9606-10-S14-22 #8 14 mm M22x1.5 3. Female pipe (NPTF)
9606-10-S16-24 #8 16 mm M24x1.5
9606-12-S16-24 #12 16 mm M24x1.5
9606-12-S20-30 #12 20 mm M30x2
9606-12-S25-36 #12 25 mm M36x2 Item Number 1. 2. 3. Price
9606-16-S20-30 #16 20 mm M30x2 9607-02-12 * 1/8" n/a M12x1.5 P.O.R.
9606-16-S25-36 #16 25 mm M36x2 9607-02-LL06-10 1/8" 6 mm M10x1.0
Item Number 1. 2. 3. Price 9607-04-12 * 1/4" n/a M12x1.5
9605S-04-L06-12 #4 6 mm M12x1.5 9606-16-S30-42 #16 30 mm M42x2 9607-04-12X1.25 1/4" n/a M12x1.25 P.O.R. Item Number 1. 2. 3. Price
9605S-04-L08-14 #4 8 mm M14x1.5 9606-20-S30-42 1-14/" 30 mm M42x2 9607-06-L12-18 3/8" 12 mm M18x1.5 9635S-12-L06-04 M12x1.5 6 mm 1/4"
9605S-04-LL06-10 #4 6 mm M10x1.0 9606-20-S38-52 #20 38 mm M52x2 9607-08-16 * 1/2" n/a M16x1.5 P.O.R. 9635S-12-L06-06 M12x1.5 6 mm 3/8"
9605S-04-LL08-12 #4 8 mm M12x1.0 9606-24-S38-52 #24 38 mm M52x2 9607-08-18 * 1/2" n/a M18x1.5 9635S-14-L08-04 M14x1.5 8 mm 1/4"
9605S-06-L08-14 #6 8 mm M14x1.5 9606S 9607-08-22 * 1/2" n/a M22x1.5 P.O.R. 9635S-16-L10-04 M16x1.5 10 mm 1/4"
9605S-06-L10-16 #6 10 mm M16x1.5 9607-08-S12-20 1/2" 12 mm M20x1.5 9635S-16-L10-06 M16x1.5 10 mm 3/8"
9605S-06-L12-18 #6 12 mm M18x1.5 Male JIC x Male Metric Dual Purpose * Port only (not compatible with tube applications) 9635S-18-L12-04 M18x1.5 12 mm 1/4"
9605S-06-LL08-12 #6 8 mm M12x1.0 Port or heavy series tube (DIN 2353 S) 9635S-18-L12-06 M18x1.5 12 mm 3/8"
9605S-08-L10-16 #8 10 mm M16x1.5 Includes washer and O-ring 9624 9635S-18-L12-08 M18x1.5 12 mm 1/2"
9605S-08-L12-18 #8 12 mm M18x1.5 1. Male JIC 37° Female JIC x Male Metric Dual Purpose 9635S-22-L15-06 M22x1.5 15 mm 3/8"
9605S-08-L15-22 #8 15 mm M22x1.5 2. Nominal tube O.D. Port or tube (DIN 2353 L light series or DIN 2353 S heavy series) 9635S-22-L15-08 M22x1.5 15 mm 1/2"
9605S-10-L15-22 #8 15 mm M22x1.5 3. Male metric thread 1. Female JIC 37° solid 9635S-22-L15-12 M22x1.5 15 mm 3/4"
9605S-10-L18-26 #8 18 mm M26x1.5 2. Nominal tube O.D. 9635S-26-L18-12 M26x1.5 18 mm 3/4"
9605S-12-L15-22 #12 15 mm M22x1.5 3. Male metric thread 9635S-30-L22-12 M30x2.0 22 mm 3/4"
9605S-12-L18-26 #12 18 mm M26x1.5 9636S-20-S12-04 M20x1.5 12 mm 1/4"
9605S-12-L22-30 #12 22 mm M30x2 9636S-24-S16-12 M24x1.5 16 mm 3/4"
9605S-16-L28-36 #16 28 mm M36x2 9636S-42-S30-16 M42x2.0 30 mm 1"
9605S-20-L35-45 #20 35 mm M45 x2 9636S-42-S30-20 M42x2.0 30 mm 1¼"
9605S-24-L42-52 #24 42 mm M52x2 Item Number 1. 2. 3. Price
9606S-04-S06-14 #4 6 mm M14x1.5 9636S
9606 9606S-04-S08-16 #4 8 mm M16x1.5 Item Number 1. 2. 3. Price Male Metric DIN (Heavy Duty) Comes w/ Washer
Male JIC x Male Metric Dual Purpose 9606S-06-S08-16 #6 8 mm M16x1.5 9624-04-L06-12 #4 6 mm M12x1.5 & O-Ring X Female NPT
6 mm
M14x1.5
#4
9624-04-S06-14
Port or heavy series tube (DIN 2353 S) 9606S-06-S10-18 #6 10 mm M18x1.5
9606S-06-S12-20 #6 12 mm M20x1.5 9624-06-L08-14 #6 8 mm M14x1.5
1. Male JIC 37° 9606S-06-S14-22 #6 14 mm M22x1.5 9624-06-L10-16 #6 10 mm M16x1.5 1. Male metric thread
2. Nominal tube O.D. 9606S-08-S10-18 #8 10 mm M18x1.5 9624-06-S08-16 #6 8 mm M16x1.5 2. Nominal tube O.D.
3. Male metric thread 3. Female pipe (NPTF)
9606S-08-S12-20 #8 12 mm M20x1.5 9624-06-S10-18 #6 10 mm M18x1.5
9606S-08-S16-24 #8 16 mm M24x1.5 9624-08-L12-18 #8 12 mm M18x1.5
9606S-10-S12-20 #8 12 mm M20x1.5 9624-08-L15-22 #8 15 mm M22x1.5
9606S-10-S16-24 #8 16 mm M24x1.5 9624-08-S12-20 #8 12 mm M20x1.5
9606S-12-S16-24 #12 16 mm M24x1.5 9624-08-S14-22 #8 14 mm M22x1.5
Item Number 1. 2. 3. Price 9606S-12-S20-30 #12 20 mm M30x2.0 9624-08-S16-24 #8 16 mm M24x1.5
18 mm
#12
M26x1.5
9624-12-L18-26
9606-04-S06-14 #4 6 mm M14x1.5 9606S-12-S25-36 #12 25 mm M36x2.0 9624-12-L22-30 #12 22 mm M30x2.0
9606-04-S08-16 #4 8 mm M16x1.5 9606S-16-S20-30 #16 20 mm M30x2.0 9624-12-S20-30 #12 20 mm M30x2.0 Item Number 1. 2. 3. Price
9606-04-S10-18 #4 10 mm M18x1.5 9606S-16-S25-36 #16 25 mm M36x2.0 9624-16-L28-36 #16 28 mm M36x2.0 9636S-20-S12-04 M20x1.5 12 mm 1/4"
9606-06-S08-16 #6 8 mm M16x1.5 9606S-16-S30-42 #16 30 mm M42x2.0 9624-16-S25-36 #16 25 mm M36x2.0 9636S-24-S16-12 M24x1.5 16 mm 3/4"
9606-06-S10-18 #6 10 mm M18x1.5 9606S-20-S30-42 1-14/" 30 mm M42x2.0 9624-20-S30-42 #20 30 mm M42x2.0 9636S-42-S30-16 M42x2.0 30 mm 1"
9606-06-S12-20 #6 12 mm M20x1.5 9606S-20-S38-52 #20 38 mm M52x2.0 9624-24-L35-45 #24 35 mm M45x2.0 9636S-42-S30-20 M42x2.0 30 mm 1¼"
9606-06-S14-22 #6 14 mm M22x1.5 9606S-24-S38-52 #24 38 mm M52x2.0 9624-24-L42-52 #24 42 mm M52x2.0
9606-08-S10-18 #8 10 mm M18x1.5 9624-24-S38-52 #24 38 mm M52x2.0
"C" suffix = Complete Assembly - Includes Nut and Sleeve "C" suffix = Complete Assembly - Includes Nut and Sleeve
