Carbon Steel Plastic Thread Fitting Identification Guage Kits
HYDRAULIC HOSE
.com ®
.com ® HYDRAULIC HOSE
9638 9777 TGK-01 TGK-02
Male Metric x Female Metric BSPP Flat-Face Sealing Seat (HIAB) Plastic Thread Fitting Identification Gauges Kit for British Plastic Thread Fitting Identification Gauges Kit for JIC
(Metric Bushing) Converts a male BSPP fitting with 30° inverted cone to a BSPP flat- and Metric Threads NPT ORB ORFS
face (includes buna O-ring)
1. Male metric The Thread Gauge Kit (TGK) is a convenient and affordable solution The Thread Gauge Kit (TGK-02) is a convenient and affordable solution
2. Female metric 1. BSPP thread size to identifying Metric and British threaded fittings in the field, shop, or to identifying Metric and British threaded fittings in the field, shop, or
store front. Featuring one British (BSPP, BSPT, JIS) tool and one Metric store front.
(MM, DIN, Kobelco, Komatsu) tool in a vinyl pouch, this tool allows you Includes 4 plastic gauge cards. One for JIC/ORB, one for NPT, One for
to identify internal threads, external threads, thread pitch, as well as O-Ring Face Seal, and one angle gauge/ruler in leather bound cases.
chamfer and nose cone angles specific to JIS, BSPP, Komatsu, Kobelco,
and 30/60 degree Metric.

Item Number 1. 2. Price Item Number 1. Price
9638-14X1.5-10X1.0 M14x1.5 M10x1.0 P.O.R. 9777-06 3/8" P.O.R.
9638-16X1.5-12X1.5 M16x1.5 M12x1.5 P.O.R. 9777-08 1/2"
9638-18X1.5-14X1.5 M18x1.5 M14x1.5 9777-12 3/4" P.O.R.
9638-18X1.5-27X2.0 M18x1.5 M27x2.0 P.O.R.
9638-20X1.5-16X1.5 M20x1.5 M16x1.5 P.O.R.
9638-22X1.5-14X1.5 M22x1.5 M14x1.5 9999
9638-22X1.5-18X1.5 M22x1.5 M18x1.5 P.O.R. JIS Sealing Seat
9638-24X1.5-20X1.5 M24x1.5 M20x1.5 P.O.R. Converts a male BSPP to JIS
9638-26X1.5-22X1.5 M26x1.5 M22x1.5 P.O.R. 1. BSPP thread size
9638-27X2.0-18X1.5 M27x2.0 M18x1.5 ORFS Thread Size
9638-30X2.0-26X1.5 M30x2.0 M26x1.5 P.O.R. British Thread Size
9638-33X2.0-14X1.5 M33x2.0 M14x1.5 P.O.R.
9638-42X2.0-14X1.5 M42x2.0 M14x1.5 P.O.R.
9638-48X2.0-42X2.0 M48x2.0 M42x2.0 P.O.R.

9643 ORB Thread Sizes
Female Pipe (NPTF) x Female Metric
1. Female pipe (NPTF) Item Number 1. Price
2. Female metric 9999-02 1/8" P.O.R. Metric Thread Sizes
9999-04 1/4"
9999-06 3/8"
9999-08 1/2"
9999-10 5/8" P.O.R. NPT Thread Sizes
Item Number 1. 2. Price 9999-12 3/4"
9643-02-06X1.0 1/8" M6x1.0 P.O.R. 9999-16 1"
9643-02-08X1.0 1/8" M8x1.0 P.O.R. 9999-20 1¼"
9643-02-10X1.0 1/8" M10x1.0 P.O.R. 9999-24 1½" Item Number Price
9643-04-12X1.5 1/4" M12x1.5 TGK-01 British & Metric JIC Thread Sizes
9643-04-14X1.5 1/4" M14x1.5
9643-04-16X1.5 1/4" M16x1.5

Item Number Price
TGK-02 JIC, NPT, ORB, ORFS

"C" suffix = Complete Assembly - Includes Nut and Sleeve "C" suffix = Complete Assembly - Includes Nut and Sleeve
