Page 78 - DHH Catalog

SAE J518 Four Bolt Flanges HYDRAULIC HOSE
.com ®

W48 W304 W604
Female O-Ring Boss x ORFS x Code 61 Flange ORFS x Code 62 Flange
Code 62 Flange Pad Pad Pad

Flange Pad Only: Flange Pad Only: Flange Pad Only:
W304-08-08
W48-08-08 W604-08-08
W304-12-12
W48-12-12 W604-12-12
W304-16-16
W48-16-16 W604-16-16
W304-20-20
W48-20-20 W604-20-20
W304-24-24
W48-24-24 W604-24-24
W48-32-32 W304 Kit (includes O-ring, bolts, W604 Kit (includes O-ring, bolts,
and lock washers)
W48 Kit (includes O-ring, bolts, and lock washers)
and lock washers) W304-08-08U
W604-08-08U
W304-12-12U
W48-08-08U W604-12-12U
W304-16-16U
W48-12-12U W604-16-16U
W304-20-20U
W48-16-16U W604-20-20U
W304-24-24U
W48-20-20U W604-24-24U
W48-24-24U
W600
W48-32-32U
JIC x Code 62 Flange Pad
W300
JIC x Code 61 Flange Pad

Flange Pad Only:
W600-08-08
W600-12-12
Flange Pad Only:
W600-16-16
W300-08-08 W600-20-20
W300-12-12 W600-24-24 Don't see what you need?
W300-16-16 W600 Kit (includes O-ring, bolts,
W300-20-20 and lock washers) Give us a call!
W300-24-24
W600-08-08U We are an authorized Anchor
W300 Kit (includes O-ring, bolts,
W600-12-12U
and lock washers) Fluid Power Distributor!
W600-16-16U
W300-08-08U W600-20-20U
W300-12-12U W600-24-24U
W300-16-16U
W300-20-20U
W300-24-24U

Page 76 800-535-1302 • SAVE 6% WHEN YOU BUY ONLINE at www.DiscountHydraulicHose.com ST2003
