Fluid Conducting Swivel Joints
HYDRAULIC HOSE
.com ®

ORFS x NPTF ORFS x ORFS ORFS x SAE ORFS x SAE
90° Swivel 90° Swivel 90° Swivel 90° Swivel

O-Ring Face Seal Male
O-Ring Face Seal Fem. Union O-Ring Face Seal Fem. Union O-Ring Face Seal Fem. Union
SAE Straight Thread O-Ring
NPTF Female Pipe O-Ring Face Seal Female SAE Straight Thread O-Ring
9S4-F4-O4
9S4-FU4-PF4 9S4-FU4-FF4 9S4-FU4-O4
9S6-FU6-PF4 9S6-FU6-FF6 9S4-F4-O5 9S4-FU4-O5
9S6-FU6-PF6 9S6-FU6-FF8 9S6-F4-O6 9S6-FU6-O4
9S8-FU8-PF8 9S8-FU8-FF8 9S6-F6-O4 9S6-FU6-O5
9S8-FU10-PF8 9S6-F6-O5
9S8-FU8-FF10 9S6-FU6-O6
9S12-FU12-PF12 9S6-F6-O6
9S16-FU16-PF16 9S8-FU10-FF8 9S6-F6-O8 9S6-FU6-O8
9S20-FU20-PF20 9S8-FU10-FF10 9S6-F8-O4 9S8-FU8-O8
9S24-FU24-PF24 9S12-FU12-FF12 9S8-FU8-O10
9S6-F8-O5
9S16-FU16-FF16 9S8-FU8-O12
ORFS x ORFS 9S20-FU20-FF20 9S6-F8-O6 9S8-FU10-O8
90° Swivel 9S24-FU24-FF24 9S6-F8-O8 9S8-FU10-O10
9S8-F8-O8
9S8-FU10-O12
9S8-F8-O10
9S12-FU12-O12
9S8-F8-O12
9S16-FU16-O16
9S8-F10-O8
9S20-FU20-O20
9S8-F10-O10
9S24-FU24-O24
9S8-F10-O12
9S12-F12-O12
9S16-F16-O16
O-Ring Face Seal Fem. Union
9S20-F20-O20
O-Ring Face Seal Male
9S24-F24-O24
9S4-FU4-F4
9S6-FU6-F6
9S6-FU6-F8
9S8-FU8-F8
9S8-FU8-F10
9S8-FU10-F8
9S8-FU10-F10
9S12-FU12-F12
9S16-FU16-F16
9S20-FU20-F20
9S24-FU24-F24

Fluid conducting swivel joints
