Push-In Air Brake Fittings for Nylon Tubing HYDRAULIC HOSE
.com ®

31871S 31872S 31880 31880S
Air Brake x Male Pipe Air Brake x Male Pipe Air Brake x Male Pipe Air Brake x Male Pipe
Swivel Run Tee Swivel Branch Tee 45° Elbow Swivel 45° Elbow

(1) tube, (2) NPTF male swivel, (1) tube, (2) NPTF male (1) tube, (2) NPTF male swivel
(3) tube (1,2) tube, (3) NPTF male swivel Ref. SAE # AA0302 Ref. SAE # AA03DD
Ref. SAE # AA04EE Ref. SAE # AA04FF
31880-04-02
31871S-04-02-04 31872S-04-04-02 31880-04-04 31880S-04-02
31880S-04-04
31871S-04-04-04 31872S-04-04-04 31880-06-04 31880S-06-04
31871S-06-04-06 31872S-06-06-04 31880-06-06 31880S-06-06
31871S-06-06-06 31872S-06-06-06 31880-08-04 31880S-08-04
31871S-08-06-08 31872S-08-08-06 31880-08-06 31880S-08-06
31871S-08-08-08 31872S-08-08-08 31880-08-08
31880S-08-08
31880-10-08 31880S-10-08
31872 31874 31880-12-08
Air Brake x Male Pipe Air Brake Bulkhead Union 31880-12-12
Branch Tee
Plastic Tube and
(1) tube, (2) tube Hose Cutter
Ref. SAE # AA0601
Cuts plastic tubing and hose
31874-04-04 up to 1/2" OD. Mounts on
(1) tube, (2) tube, (3) NPTF male 31874-06-06 bench or wall. Designed to
swivel
31874-08-08 close automatically for safety
Ref. SAE # AA0425 when not in use.
31874-10-10
31872-04-04-02 Not for use with wire-reinforced hose.
31872-04-04-04
DT191 Plastic Tube Cutter
31872-06-06-04
DT191B Replacement Blade
31872-06-06-06
31872-08-08-06
31872-08-08-08

31402
Quick Fix DOT Air
Brake Repair Kit

Quick Fix Kit for 3/8" DOT A, AI, and A
II 10MM (3/8" ID) Air Brake Hose
Includes 2 Non-Reusable 3/8" Male
NPTF Swivel Ends

Meets all applicable SAE and DOT specifi cations.
Use with NT100 Nylon Air Brake Tubing (See Pg. 8)
