Air Brake Fittings for Nylon Tubing HYDRAULIC HOSE
.com ®

31470 31471
Female Pipe, 90° Elbow Male Pipe Run Tee Air Brake Coiled Hose Kit
Hose kit includes two hoses (1 red and 1 blue)
pre-assembled for immediate installation.
Maximum working pressure: 150 psi
Temperature range: -40° to 200° F
(1) tube, (2) NPTF female Conforms to DOT FMVSS 571.106,
(1) tube, (2) NPTF male, (3) tube
Ref. SAE # 100203BA SAE J844 Type B, and SAE J1131.
Ref. SAE # 100424BA
31470-04-02
31471-04-02-04 Item # Hose Length Pigtail Price
31470-04-04
31471-04-04-04 3W1206 12 feet 6 inches
31470-06-02
31471-06-04-04 3W1212 12 feet 12 inches
31470-06-04
31471-06-04-06 3W1512 15 feet 12 inches
31470-06-06
31471-06-06-06
31470-08-06
31471-08-06-08
31470-08-08
31471-08-08-08 31480 31482
31470-10-08
31471-10-08-04 Air Brake x Male Pipe Air Brake x Female Pipe x
31471-10-08-10 45° Elbow Male Pipe Tee
31474
31471-12-12-12
Air Brake Bulkhead
Tube Union
31472
Male Pipe Branch Tee
(1) tube, (2) NPTF female,
(1) tube, (2) NPTF male (3) NPTF male
(1) tube, (2) tube Ref. SAE # 100302BA
31482-06-04-04
31474-04-04 31480-04-02 31482-06-04-06
31474-06-06 31480-04-04 31482-10-04-08
(1) tube, (2) tube, (3) NPTF male
31474-08-08 31480-06-02
Ref. SAE # 100425BA
31474-12-12 31480-06-04
31472-04-04-02 31480-06-06
31472-04-04-04 31480-08-04
31472-06-04-04 31480-08-06
31472-06-06-02 31480-08-08
31472-06-06-04 31480-10-08
31472-06-06-06
31472-08-08-04
31472-08-08-06
31472-08-08-08
31472-10-10-04
31472-10-10-08
31472-12-12-12

Meets all applicable SAE and DOT specifi cations.
Use with NT100 Nylon Air Brake Tubing (See Pg. 8)
