Page 104 - DHH Catalog

Air Brake Fittings for Copper Tubing HYDRAULIC HOSE
.com ®

31371 31380 Bulkhead Couplings
Air Brake x Male Pipe Air Brake x Female Pipe
Run Tee 45° Elbow
NPTF Male x Female

(1) tube, (2) NPTF male
(1) tube, (2) NPTF male, (3) tube Ref. SAE # 120302BA Item # Male Female Length Material Price
Ref. SAE # 120424BA 35498 1/2" 1/4" 2.16" Steel
31380-04-02
35499 1/2" 1/4" 2.53" Steel
31371-04-02-04 31380-04-04
31340 1/2" 1/4" 2.16" Brass
31371-04-04-04 31380-06-02
31341 1/2" 1/4" 2.53" Brass
31371-06-04-06 31380-06-04
31371-06-04-04 31380-06-06
NPTF Male x NPTF Dual (Male and Female)
31371-06-06-06 31380-08-06
31371-08-06-08 31380-08-08
31371-08-08-08 31380-10-08
31371-10-08-10
31371-10-08-04 31382
Air Brake x Female Pipe Item # Male Female Length Material Price
31372 x Male Pipe Tee 31342 1/2" 1/4" 2.94" Brass
Air Brake x Male Pipe 31343 1/2" 1/4" 3.94" Brass
Branch Tee
NPTF Female x Female
(1) tube, (2) NPTF female,
(3) NPTF male
31382-06-04-04
(1) tube, (2) tube, (3) NPTF male
Ref. SAE # 120425BA Item # NPTF Length Material Price
00397-03 1/4" 0.94" Brass
31372-04-04-02
00397-04 1/4" 1.50" Brass
31372-04-04-04
00397-06 3/8" 1.31" Brass
31372-06-06-02
00397-08 1/2" 1.50" Brass
31372-06-06-04
305465 1/4" 1.50" Steel
31372-06-04-04
321204 1/4" 0.94" Steel
31372-06-06-06
317709 3/8" 1.31" Steel
31372-08-08-06
31372-08-08-08
31372-10-10-04
31372-10-10-08

Meets all applicable SAE and DOT specifi cations.
Use with 972C Copper Tubing.
