W Series Hose Fittings HYDRAULIC HOSE
.com ®

FBSPX FBSPX90 MBSPP FKOMX
British Standard Pipe British Standard Pipe British Standard Pipe Komatsu (Metric JIS)
Female Swivel Female Swivel 90° Parallel Male Rigid Female Swivel

FKOMX-04-14W
FBSPX-04-04W MBSPP-04-04W
FKOMX-06-14W
FBSPX-04-06W MBSPP-04-06W
FKOMX-06-18W
FBSPX-06-06W FBSPX90-04-04W MBSPP-06-06W
FKOMX-08-22W
FBSPX-06-08W FBSPX90-04-06W MBSPP-06-08W
FKOMX-08-24W
FBSPX-08-08W FBSPX90-06-06W MBSPP-08-08W
FKOMX-10-24W
FBSPX-08-10W FBSPX90-06-08W MBSPP-08-10W
FKOMX-12-30W
FBSPX-10-10W FBSPX90-08-08W MBSPP-12-12W
FKOMX-16-33W
FBSPX-12-12W FBSPX90-10-10W
FBSPX-16-16W FBSPX90-12-12W
FJISX
FBSPX-20-20W FBSPX90-16-16W
Japanese Industrial
FBSPX-24-24W
Standard (JIS 30°) Female
Swivel
FBSPX45
British Standard Pipe
Female Swivel 45°
Threads are similar to BSPP.
FJISX-04-04W
FJISX-06-06W
FJISX-08-08W
FBSPX45-04-04W
FJISX-10-10W
FBSPX45-06-06W
FJISX-12-12W
FBSPX45-08-08W
FJISX-16-16W
FBSPX45-10-10W
FBSPX45-12-12W
FBSPX45-16-16W

British and Metric Thread Identifi cation Kit (ID-Kit)

Thread Identifi cation Kit for male and female threads includes 31 dual-threaded, heat-treated
aluminum gauges that allow you to identify Metric and BSPP threads quickly.
• M8x1 through M52x2 metric thread gauges
• 1/8-28 BSPP through 2-11 BSPP thread gauges
• Carrying case
• Thread and Port Guide
