W Series Hose Fittings
HYDRAULIC HOSE
.com ®

FDL FDL90 FDH FDH90
DIN Light (Metric) DIN Light (Metric) DIN Heavy (Metric) DIN Heavy (Metric)
Universal Seat Universal Seat Universal Seat Universal Seat
Female Swivel Female Swivel 90° Female Swivel Female Swivel 90°

FDL-04-08-14W FDH-04-08-16W
FDL-04-10-16W FDH-04-10-18W
FDL-06-10-16W FDL90-04-08-14W FDH-06-08-16W FDH90-04-08-16W
FDL-06-12-18W FDL90-04-10-16W FDH-06-12-20W FDH90-04-10-18W
FDL-06-15-22W FDL90-06-10-16W FDH-06-14-22W FDH90-06-08-16W
FDL-08-15-22W FDL90-06-12-18W FDH-08-16-24W FDH90-06-12-20W
FDL-08-18-26W FDL90-08-15-22W FDH-10-20-30W FDH90-06-14-22W
FDL-10-18-26W FDL90-08-18-26W FDH-12-20-30W FDH90-08-12-20W
FDL-12-18-26W FDL90-10-18-26W FDH-12-25-36W FDH90-08-16-24W
FDL-12-22-30W FDL90-12-18-26W FDH-16-30-42W FDH90-10-20-30W
FDL-16-28-36W FDL90-12-22-30W FDH-20-30-42W FDH90-12-20-30W
FDL-20-35-45W FDL90-16-28-36W FDH-20-38-52W FDH90-12-25-36W
FDL90-20-35-45W FDH-24-38-52W FDH90-16-30-42W
FDL45 FDH90-20-30-42W
DIN Light (Metric) MDL FDH45 FDH90-20-38-52W
Universal Seat DIN Light (Metric) DIN Heavy (Metric)
Female Swivel 45° Universal Seat Male Universal Seat MDH
Female Swivel 45° DIN Heavy (Metric)
Universal Seat Male

MDL-04-08-14W
FDL45-04-08-14W MDL-04-10-16W
FDL45-04-10-16W MDL-06-10-16W FDH45-04-08-16W MDH-04-08-16W
FDL45-06-10-16W MDL-06-12-18W FDH45-04-10-18W MDH-04-10-18W
FDL45-06-12-18W MDL-06-15-22W FDH45-06-08-16W MDH-06-08-16W
FDL45-08-15-22W MDL-08-12-18W FDH45-06-12-20W MDH-06-12-20W
FDL45-10-18-26W MDL-08-15-22W FDH45-06-14-22W MDH-06-14-22W
FDL45-12-18-26W MDL-10-18-26W FDH45-08-12-20W MDH-08-16-24W
FDL45-12-22-30W MDL-12-22-30W FDH45-08-16-24W MDH-10-20-30W
FDL45-16-28-36W MDL-16-28-36W FDH45-10-20-30W MDH-12-25-36W
FDL45-20-35-45W FDH45-12-20-30W MDH-16-30-42W
FDH45-12-25-36W
FDH45-16-30-42W
FDH45-20-30-42W
FDH45-20-38-52W

Hose Size
MDH- 08 - 16 - 24

Tube O.D. (mm)
Thread O.D. (mm)
