3 Series Thermoplastic Hose Fittings
HYDRAULIC HOSE
.com ®

NPTF Male Pipe JIC 37° Female Swivel

Item # Hose NPTF Die Pusher Price Most sizes (except 3/8" and 3/4") are dual seat, will fi t JIC 37° and SAE 45°
3-02102 1/8" 1/8" 4540-302 4599-MP023
Item # Hose JIC Die Pusher Price
3-03102 3/16" 1/8" 4540-303 4599-MP001
3-02544 1/8" 1/4" 4540-302 4599-FP010
3-03104 3/16" 1/4" 4540-303 4599-MP004
3-03544 3/16" 1/4" 4540-303 4599-FP011
3-04102 1/4" 1/8" 4540-304 4599-MP002
3-04544 1/4" 1/4" 4540-304 4599-FP012
3-04104 1/4" 1/4" 4540-304 4599-MP004
3-04545 1/4" 5/16" 4540-304 4599-FP013
3-04106 1/4" 3/8" 4540-304 4599-MP005
3-04546 1/4" 3/8" 4540-304 4599-FP013
3-05104 5/16" 1/4" 4540-305 4599-MP004
3-05545 5/16" 5/16" 4540-305 4599-FP013
3-05106 5/16" 3/8" 4540-305 4599-MP005
3-05546 5/16" 3/8" 4540-305 4599-FP013
3-06104 3/8" 1/4" 4540-306 4599-MP005
3-06546 3/8" 3/8" 4540-306 4599-FP015
3-06106 3/8" 3/8" 4540-306 4599-MP005
3-06548 3/8" 1/2" 4540-306 4599-FP005
3-06108 3/8" 1/2" 4540-306 4599-MP009
3-08548 1/2" 1/2" 4540-308 4599-FP016
3-08106 1/2" 3/8" 4540-308 4599-MP008
3-08550 1/2" 5/8" 4540-308 4599-FP006
3-08108 1/2" 1/2" 4540-308 4599-MP009
3-12552 3/4" 3/4" 4540-312 4599-FP008
3-12112 3/4" 3/4" 4540-312 4599-MP011
3-16116 1" 1" 4540-316 4599-MP013
SAE 45° Swivel
NPTF Male Pipe Swivel
For all other sizes, use JIC 37° Female Swivel
Item # Hose SAE Die Pusher Price
Item # Hose NPTF Die Pusher Price
3-06A06 3/8" 3/8" 4540-306 4599-FP014
3-03144 3/16" 1/4" 4540-303 4599-MP003
3-04144 1/4" 1/4" 4540-304 4599-MP003
3-06146 3/8" 3/8" 4540-306 4599-MP006 JIC 37° Male
3-08148 1/2" 1/2" 4540-308 4599-MP010

NPSM Female Pipe Swivel
Item # Hose JIC Die Pusher Price
3-03504 3/16" 1/4" 4540-303 4599-MP001
3-04504 1/4" 1/4" 4540-304 4599-MP002
3-04505 1/4" 5/16" 4540-304 4599-MP002
Item # Hose NPSM Die Pusher Price
3-04506 1/4" 3/8" 4540-304 4599-MP005
3-03244 3/16" 1/4" 4540-303 4599-FP002
3-05506 5/16" 3/8" 4540-305 4599-MP004
3-04244 1/4" 1/4" 4540-304 4599-FP002
3-06506 3/8" 3/8" 4540-306 4599-MP005
3-06246 3/8" 3/8" 4540-306 4599-FP004
3-06508 3/8" 1/2" 4540-306 4599-MP007
3-08248 1/2" 1/2" 4540-308 4599-FP018
3-08508 1/2" 1/2" 4540-308 4599-MP008
3-08510 1/2" 5/8" 4540-308 4599-MP009

3 Series Thermoplastic Hose Fittings are intended for use with
SAE 100R7 or 100R8 Thermoplastic Hose.
• Interchangeable with Synfl ex 3903 Series Hose Fittings
• Can be attached with a hose crimper or with the DST1
Swaging Tool (page 149).

HH2003 800-535-1302 • SAVE 6% WHEN YOU BUY ONLINE at www.DiscountHydraulicHose.com Page 29
