Page 126 - DHH Catalog

Brass Ball Valves HYDRAULIC HOSE
.com ®

Full-Port Forged Brass Ball Valves Chrome Plated Mini Brass Ball Valves

Maximum working pressure: 235 psi
(will handle 300 psi @ 75° F)
• Solid chrome plated brass ball
• Longer body style for longer, deeper thread connections
• One piece drawn sand blasted chrome plated body
• Each valve is seal tested for maximum safety
• Double seal system allows valve to operate in both directions
With forged brass bodies for strength, and solid chrome-plated balls, • Blowout-proof brass stem
these valves are suitable for a wide range of liquids and gases. Full-size • Temperature range: 32º F to 176º F
ports minimize pressure drop and allow full fl ow in both directions.
• 600 psi WOG (non shock) and 150 WSP saturated steam Male NPTF x Female NPTF Female NPTF
• Virgin PTFE stem packing seal, thrust washer and seats.
• Yellow vinyl insulator on heavy-duty plated steel handle.
• Fast one-quarter turn open or close operation.
• Low operating torque.
• Adjustable stem packing gland.
• Bottom-entry, blow-out proof stem.
Item # NPTF Price Item # NPTF Price
• Temperature range: -20º F to 248º F 46-903I 1/4" 46-922I 1/4"
Threaded ports (NPTF) 46-904I 3/8" 46-923I 3/8"
46-905I 1/2" 46-924I 1/2"
Item # NPTF Minimum Price
943-200 1/4"
943-200-BX20 1/4" 20 valves @
943-201 3/8"
943-201-BX20 3/8" 20 valves @
943-202 1/2"
943-202-BX50 1/2" 50 valves @
943-202-CS100 1/2" 100 valves @
943-203 3/4"
943-203-BX30 3/4" 30 valves @
943-203-CS60 3/4" 60 valves @
943-204 1"
943-204-BX20 1" 20 valves @
943-204-CS40 1" 40 valves @
943-205 1¼"
943-205-BX12 1¼" 12 valves @
943-205-CS24 1¼" 24 valves @
943-206 1½"
943-206-BX9 1½" 9 valves @
943-206-CS18 1½" 18- valves @
943-207 2"
Sweat (SWT)
Item # SWT Price
940-212 1/2"
940-213 3/4"
940-214 1"
940-215 1¼"
940-216 1½"
940-217 2"
