Page 130 - DHH Catalog

Hydraulic Quick Couplers HYDRAULIC HOSE
.com ®

Buy a set and save. Each pair includes 1 female AG Series
ISO 5675 Female Couplers ISO 5675 Matched Sets/Pairs
coupler and 1 male plug/nipple. ISO 5675
Agricultural Hydraulic
Quick Couplers

Item # Body Thread Size Price
2AGF2 1/4" 1/4-18 NPTF
3AGF3 3/8" 3/8-18 NPTF Item # Thread Size Price
4AGF4 1/2" 1/2-14 NPTF 2AGF2-AG2F2 1/4-18 NPTF
4AGF6 1/2" 3/4-14 NPTF 3AGF3-AG3F3 3/8-18 NPTF
4AGOF4 1/2" 3/4-16 SAE 4AGF4-AG4F4 1/2-14 NPTF
4AGOF5 1/2" 7/8-14 SAE 6AGF6-AG6F6 3/4-14 NPTF
6AGF6 3/4" 3/4-14 NPTF 8AGF8-AG8F8 1-11½ NPTF Recommended for use with
8AGF8 3/4" 1-11½ NPTF construction equipment, farm
implements, and most other
Elastomer Dust Plugs & Caps mobile equipment. Features
ISO 5675 Male Plug/Nipples Caps (for female couplers) and plugs (for male Buna seals, double shut-off , and
plugs/nipples) are compatible with all ISO proven ball-lock mechanism for
5675 quick disconnect couplers. positive connection.

Pressure & Flow Ratings
Maximum
Item # Body Thread Size Price Working Maximum
AG2F2 1/4" 1/4-18 NPTF Body Pressure Flow Rate
Size (psi) (gpm)
AG3F3 3/8" 3/8-18 NPTF
Item # Description Price 1/4" 5,075 3.2
AG4F4 1/2" 1/2-14 NPTF
2AGDP 1/4" Dust Plug 3/8" 4,350 7
AG4F6 1/2" 3/4-14 NPTF
3AGDP 3/8" Dust Plug 1/2" 4,350 12
AG4OF4 1/2" 3/4-16 SAE
4AGDP 1/2" Dust Plug 3/4" 3,625 20
AG4OF5 1/2" 7/8-14 SAE
6AGDP 3/4" Dust Plug 1" 3,190 40
AG6F6 3/4" 3/4-14 NPTF
8AGDP 1" Dust Plug
AG8F8 3/4" 1-11½ NPTF
AG2DC 1/4" Dust Cap
Interchanges with:
AG3DC 3/8" Dust Cap
AG4DC 1/2" Dust Cap • Parker 4000 Series
AG6DC 3/4" Dust Cap • Safeway Series ‘S20’
• Faster ‘NS’
AG8DC 1" Dust Cap
• Tomco Series ‘PC’
1/2" also interchanges
with ISO 7241-1 Series A
