Cam & Groove
HYDRAULIC HOSE
.com ®

Specifi cations Type A Type B
Male Adapter x Female NPTF Female Coupler x Male NPTF
Our aluminum and brass cam and groove
fi ttings are designed to interchange with all
product manufactured to Mil-C-27487F.
No standard exists for 1/2" and 8" fi ttings, and
generally these sizes do not interchange with
other manufacturers.

Pressure ratings with standard seals at 70° F. Aluminum
Body NPT Item # Price
Aluminum
1/2" 1/2" 50-A-AL
Maximum
Working Maximum 3/4" 1/2" 7550-A-AL Body NPT Item # Price
Pressure Working Pressure 3/4" 3/4" 75-A-AL 1/2" 1/2" 50-B-AL
Body Aluminum & Polypropylene
Size Brass (psi) (psi) 1" 1" 100-A-AL 3/4" 3/4" 75-B-AL
1/2" 150 125 1¼" 1¼" 125-A-AL 1" 1" 100-B-AL
3/4" 250 125 1½" 1½" 150-A-AL 1½" 1½" 150-B-AL
1" 250 125 2" 2" 200-A-AL 2" 2" 200-B-AL
1-1/4" 250 100 2½" 2½" 250-A-AL 3" 3" 300-B-AL
1-1/2" 250 100 3" 3" 300-A-AL 4" 4" 400-B-AL
2" 250 100 4" 4" 400-A-AL 5" 5" 500-B-AL
2-1/2" 150 100 5" 5" 500-A-AL 6" 6" 600-B-AL
3" 125 70 6" 6" 600-A-AL 8" 8" 800-B-AL
4" 100 N/A 8" 8" 800-A-AL Brass
5" 75 N/A Brass
6" 75 N/A Body NPT Item # Price
Body NPT Item # Price 1/2" 1/2" 50-B-BR
8" N/A N/A
1/2" 1/2" 50-A-BR 3/4" 3/4" 75-B-BR
Polypropylene cam and groove should not be 3/4" 1/2" 7550-A-BR 1" 1" 100-B-BR
used with aluminum fi ttings. 3/4" 3/4" 75-A-BR 1½" 1½" 150-B-BR
Aluminum and brass couplings ship with 1" 1" 100-A-BR 2" 2" 200-B-BR
Buna-N gaskets. 1¼" 1¼" 125-A-BR 3" 3" 300-B-BR
1½" 1½" 150-A-BR 4" 4" 400-B-BR
Polypropylene couplings ship with EPDM
gaskets. Polyproylene is not recommended for 2" 2" 200-A-BR Polypropylene
use with PTFE gaskets. 2½" 2½" 250-A-BR
Body NPT Item # Price
3" 3" 300-A-BR
3/4" 1/2" PPB50
4" 4" 400-A-BR
3/4" 3/4" PPB75
5" 5" 500-A-BR
1" 1" PPB100
6" 6" 600-A-BR
1½" 1¼" PPB125
Polypropylene
1½" 1½" PPB150
Body NPT Item # Price 2" 2" PPB200
3/4" 1/2" PPA50 3" 3" PPB300
3/4" 3/4" PPA75 4" 4" PPB400
1" 1" PPA100
1½" 1¼" PPA125
1½" 1½" PPA150
2" 2" PPA200
3" 3" PPA300
4" 4" PPA400

SAFETY NOTICE: Cam and groove couplings should
never be used for compressed air or steam service.
