General Purpose Quick Couplers HYDRAULIC HOSE
.com ®

H Series Steel Couplers
General Purpose Quick Disconnect
Item # Description Thread (NPT) Price
VHC04-04F 1/4" Steel Coupler 1/4" NPT (female)
VHC04-04M 1/4" Steel Coupler 1/4" NPT (male)
VHC06-06F 3/8" Steel Coupler 3/8" NPT (female)
VHC06-06M 3/8" Steel Coupler 3/8" NPT (male)
VHC08-08F 1/2" Steel Coupler 1/2" NPT (female)
VHC08-08M 1/2" Steel Coupler 1/2" NPT (male)
VHC12-12F 3/4" Steel Coupler 3/4" NPT (female)
Interchanges with: VHC12-12M 3/4" Steel Coupler 3/4" NPT (male)
• Snap-Tite H Series VHC16-16F 1" Steel Coupler 1" NPT (female)
• MIL-C-51234 VHC16-16M 1" Steel Coupler 1" NPT (male)
VHC20-20F 1¼" Steel Coupler 1¼" NPT (female)
Recommended for general hydraulic systems, plastic
molding, machine tool, test equipment, agricultural, VHC24-24F 1½" Steel Coupler 1½" NPT (female)
DOT, and other mobile hydraulics. The H Series
has been proven by years of use on food service Steel Nipples
applications and in handling of many gases and fl uids.
Item # Description Thread Price
• Superior fl ow characteristics and reliability.
VHN04-04F 1/4" Steel Nipple 1/4" NPT (female)
• Available in steel or brass.
VHN04-04M 1/4" Steel Nipple 1/4" NPT (male)
VHN06-06F 3/8" Steel Nipple 3/8" NPT (female)
Recommended
Operating Pressure (psi) VHN06-06M 3/8" Steel Nipple 3/8" NPT (male)
VHN08-08F 1/2" Steel Nipple 1/2" NPT (female)
Steel Brass Flow Rate
Body Size (gpm) VHN08-08M 1/2" Steel Nipple 1/2" NPT (male)
1/4" 6,500 2,250 4.5 VHN12-12F 3/4" Steel Nipple 3/4" NPT (female)
VHN12-12M 3/4" Steel Nipple 3/4" NPT (male)
3/8" 4,500 2,250 6.5 VHN16-16F 1" Steel Nipple 1" NPT (female)
1/2" 4,000 2,000 17 VHN16-16M 1" Steel Nipple 1" NPT (male)
VHN20-20F 1¼" Steel Nipple 1¼" NPT (female)
3/4" 3,500 2,000 35 VHN24-24F 1½" Steel Nipple 1½" NPT (female)
1" 2,000 1,750 43
1-1/4" 1,750 n/a 70

1-1/2" 1,500 n/a 107

Brass Couplers Brass Nipples
Item # Description Thread Price Item # Description Thread Price
BVHC04-04F 1/4" Brass Coupler 1/4" NPT (female) BVHN04-04F 1/4" Brass Nipple 1/4" NPT (female)
BVHC04-04M 1/4" Brass Coupler 1/4" NPT (male) BVHN04-04M 1/4" Brass Nipple 1/4" NPT (male)
BVHC06-06F 3/8" Brass Coupler 3/8" NPT (female) BVHN06-06F 3/8" Brass Nipple 3/8" NPT (female)
BVHC06-06M 3/8" Brass Coupler 3/8" NPT (male) BVHN06-06M 3/8" Brass Nipple 3/8" NPT (male)
BVHC08-08F 1/2" Brass Coupler 1/2" NPT (female) BVHN08-08F 1/2" Brass Nipple 1/2" NPT (female)
BVHC08-08M 1/2" Brass Coupler 1/2" NPT (male) BVHN08-08M 1/2" Brass Nipple 1/2" NPT (male)
BVHC12-12F 3/4" Brass Coupler 3/4" NPT (female) BVHN12-12F 3/4" Brass Nipple 3/4" NPT (female)
BVHC12-12M 3/4" Brass Coupler 3/4" NPT (male) BVHN12-12M 3/4" Brass Nipple 3/4" NPT (male)
BVHC16-16F 1" Brass Coupler 1" NPT (female) BVHN16-16F 1" Brass Nipple 1" NPT (female)
BVHC16-16M 1" Brass Coupler 1" NPT (male) BVHN16-16M 1" Brass Nipple 1" NPT (male)
