Page 143 - DHH Catalog

Pneumatic Quick Couplers
HYDRAULIC HOSE
.com ®

A Series Coupler
Astronautic Couplings Item # Description Connection Material Price
1AF1-B 1/8" Coupler 1/8" NPT (female) Brass
2AF1-B 1/4" Coupler 1/8" NPT (female) Brass
2AF2-B 1/4" Coupler 1/4" NPT (female) Brass
1AM1-B 1/8" Coupler 1/8" NPT (male) Brass
2AM1-B 1/4" Coupler 1/8" NPT (male) Brass
A Series couplers provide convenient automatic con- 2AM2-B 1/4" Coupler 1/4" NPT (male) Brass
nection and safe ‘one-handed’ disconnection. 1AS1-B 1/8" Coupler 1/8" Hose Barb Brass
• Reverse-acting sleeve prevents accidental
2AS2-B 1/4" Coupler 1/4" Hose Barb Brass
disconnection.
• Rugged construction optimizes pressure
performance and ensures corrosion resistance in Nipple
most application. Item # Description Connection Material Price
A1F1-B 1/8" Nipple 1/8" NPT (female) Brass
A2F1-B 1/4" Nipple 1/8" NPT (female) Brass
Maximum A2F2-B 1/4" Nipple 1/4" NPT (female) Brass
Body Working Maximum A1M1-B 1/8" Nipple 1/8" NPT (male) Brass
Size Pressure Flow Rate
A2M2-B 1/4" Nipple 1/4" NPT (male) Brass
1/8" 4,500 PSI 7 cfm
A2S2-S 1/4" Nipple 1/4" Hose Barb Steel
1/4" 3,000 PSI 25 cfm

Coiled Air Tool Hose Assembly
Lightweight, self-retracting hose coil
eliminates the need for reels and
other expensive take-up devices.
• 200 psi working pressure (78° F)
• 800 psi minimum burst
• One end, male pipe rigid
• One end, male pipe swivel
• Available in yellow only
ASG-1 Blow Gun
Caution: Do not use in applications where re
Ergonantic body and handle design, small, lightweight, temperature exceeds 200° F. Higher temperatures eratures
rugged, thumb lever operation, venturi holes boost out- could result in hose rupture.
put, meets OSHA and Walsh-Healey standards for safety
Item # Size Max. Working Length Price
and noise. Chrome-plated zinc body, with brass nozzle
and valve. Buna N seals. 313004-J12 1/4" 10½ feet
Ports: 1/4" NPT female 313004-J25 1/4 23½ feet
313004-J50 1/4" 47 feet
Flow: 10 cfm
313004-J100 1/4" 94 feet
Sound Level: 88 db
