Valves
HYDRAULIC HOSE
.com ®

F Series Flow Control Valves N Series Flow Control Valves

Two-step needle provides fi ne adjustments at low fl ow with three Ideal for use as speed control on hydraulic systems where a reverse fl ow
turns of the adjusting knob. The next three turns give full-open needle check is not needed. Provides excellent control and reliable shutoff in
position and conventional throttling control. When fl ow is reversed, a very small envelope. Color coded reference scale on adjusting knob
the heavy-duty poppet-retainer permits full-fl ow return capacity. Color simplifi es setting, resetting, adjusting and quick return to a previous
coded reference scale on the adjusting knob greatly simplifi es fl ow set- speed setting.
ting, resetting, adjusting and return to original fl ow. A simple set screw
locks the valve on any desired setting. Available in brass or black oxide NPTF Material Max. PSI Item # Price
steel. 1/8" Steel 5,000 SN200
1/4" Steel 5,000 SN400
NPTF Material Max. PSI Item # Price
3/8" Steel 5,000 SN600
1/8" Steel 5,000 SFC200
1/2" Steel 5,000 SN800
1/4" Steel 5,000 SFC400
3/4" Steel 3,000 SN1200
3/8" Steel 5,000 SFC600
1/8" Brass 2,000 BN200
1/2" Steel 5,000 SFC800
1/4" Brass 2,000 BN400
3/4" Steel 3,000 SFC1200
3/8" Brass 2,000 BN600
1/8" Brass 2,000 BFC200
1/2" Brass 2,000 BN800
1/4" Brass 2,000 BFC400
3/4" Brass 2,000 BN1200
3/8" Brass 2,000 BFC600
1/2" Brass 2,000 BFC800
MV Series Flow Control Valves
3/4" Brass 2,000 BFC1200
PF Series Flow Control Valves

With these high-precision metering and shutoff valves, you can readily
Utilizes a ball type check that meters fl ow in one direction and allows make fi ne adjustments and reset with the color code 500 that show
free fl ow in the reverse direction. Used to control actuator speed by when you reach the desired setting. Body components are precision-
acting as a restriction. Recommended for use in non-shock applictions. turned from solid barstock. All models have 416 stainless steel needles.
Available in brass or zinc-plated steel.
NPTF Material Max. PSI Item # Price
Cracking pressure: 5 psi
1/4" Steel 5,000 SMV400
NPTF Material Max. PSI Item # Price 3/8" Steel 5,000 SMV600
1/4" Steel 5,000 SPF400 1/2" Steel 5,000 SMV800
3/8" Steel 5,000 SPF600
1/2" Steel 5,000 SPF800
1/8" Brass 2,000 BPF200
1/4" Brass 2,000 BPF400
3/8" Brass 2,000 BPF600
1/2" Brass 2,000 BPF800

AC2003 800-535-1302 • SAVE 6% WHEN YOU BUY ONLINE at www.DiscountHydraulicHose.com Page 145
