P. 145
Mold Coolant Quick Disconnects
HYDRAULIC HOSE
.com ®
Valved Couplers with Hose Barb Unvalved Couplers with Hose Barb
Item # Body Barb Confi guration Price
2CMS2-B-E 1/4" 1/4" Hose Barb
2CMB2-B-E 1/4" 1/4" Push-Lock
Item # Body Barb Confi guration Price 2CMS2.5-B-E 1/4" 5/16" Hose Barb
2CMS2-B 1/4" 1/4" Hose Barb 2CMS3-B-E 1/4" 3/8" Hose Barb
2CMB2-B 1/4" 1/4" Push-Lock 2CMB3-B-E 1/4" 3/8" Push-Lock
2CMS2.5-B 1/4" 5/16" Hose Barb 3CMS3-B-E 3/8" 3/8" Hose Barb
2CMS3-B 1/4" 3/8" Hose Barb 3CMB3-B-E 3/8" 3/8" Push-Lock
2CMB3-B 1/4" 3/8" Push-Lock 3CMS4-B-E 3/8" 1/2" Hose Barb
3CMS3-B 3/8" 3/8" Hose Barb 3CMB4-B-E 3/8" 1/2" Push-Lock
3CMB3-B 3/8" 3/8" Push-Lock 4CMS4-B-E 1/2" 1/2" Hose Barb
3CMS4-B 3/8" 1/2" Hose Barb 4CMB4-B-E 1/2" 1/2" Push-Lock
3CMB4-B 3/8" 1/2" Push-Lock 4CMS6-B-E 1/2" 3/4" Hose Barb
Valved Couplers with 45° Hose Barb Unvalved Couplers with 45° Elbow Hose Barb
Item # Body Barb Confi guration Price
2CM4S2-B-E 1/4" 1/4" Hose Barb
2CM4B2-B-E 1/4" 1/4" Push-Lock
2CM4S2.5-B-E 1/4" 5/16" Hose Barb
2CM4S3-B-E 1/4" 3/8" Hose Barb
Item # Body Barb Confi guration Price
2CM4B3-B-E 1/4" 3/8" Push-Lock
2CM4S2-B 1/4" 1/4" Hose Barb
3CM4S3-B-E 3/8" 3/8" Hose Barb
2CM4B2-B 1/4" 1/4" Push-Lock
3CM4B3-B-E 3/8" 3/8" Push-Lock
2CM4S2.5-B 1/4" 5/16" Hose Barb
3CM4S4-B-E 3/8" 1/2" Hose Barb
2CM4S3-B 1/4" 3/8" Hose Barb
3CM4B4-B-E 3/8" 1/2" Push-Lock
2CM4B3-B 1/4" 3/8" Push-Lock
4CM4S4-B-E 1/2" 1/2" Hose Barb
3CM4S3-B 3/8" 3/8" Hose Barb
4CM4B4-B-E 1/2" 1/2" Push-Lock
3CM4B3-B 3/8" 3/8" Push-Lock
4CM4S6-B-E 1/2" 3/4" Hose Barb
3CM4S4-B 3/8" 1/2" Hose Barb
3CM4B4-B 3/8" 1/2" Push-Lock
Valved Couplers with Hose Barb Unvalved Couplers with 90° Elbow Hose Barb
Item # Body Barb Confi guration Price
2CM9S2-B-E 1/4" 1/4" Hose Barb
2CM9B2-B-E 1/4" 1/4" Push-Lock
2CM9S2.5-B-E 1/4" 5/16" Hose Barb
2CM9S3-B-E 1/4" 3/8" Hose Barb
Item # Body Barb Confi guration Price
2CM9B3-B-E 1/4" 3/8" Push-Lock
2CM9S2-B 1/4" 1/4" Hose Barb
3CM9S3-B-E 3/8" 3/8" Hose Barb
2CM9B2-B 1/4" 1/4" Push-Lock
3CM9B3-B-E 3/8" 3/8" Push-Lock
2CM9S2.5-B 1/4" 5/16" Hose Barb
3CM9S4-B-E 3/8" 1/2" Hose Barb
2CM9S3-B 1/4" 3/8" Hose Barb
3CM9B4-B-E 3/8" 1/2" Push-Lock
2CM9B3-B 1/4" 3/8" Push-Lock
4CM9S4-B-E 1/2" 1/2" Hose Barb
3CM9S3-B 3/8" 3/8" Hose Barb
4CM9B4-B-E 1/2" 1/2" Push-Lock
3CM9B3-B 3/8" 3/8" Push-Lock
3CM9S4-B 3/8" 1/2" Hose Barb
3CM9B4-B 3/8" 1/2" Push-Lock
AC2003 800-535-1302 • SAVE 6% WHEN YOU BUY ONLINE at www.DiscountHydraulicHose.com Page 143
