Page 149 - DHH Catalog

Hydraulic Hose Crimpers
HYDRAULIC HOSE
.com ®

D-Series Hydraulic Hose Crimpers
Lightweight portable
accommodate a wide range of models are ideal for
emergency repairs in
hose and fi tting types. the fi eld
Heavy-duty cylinder
Unlike some crimpers that only work with one (D100 Series) delivers
up to 35 tons of
brand of hose and fi ttings, our D-Series Hydraulic
crimping force
Hose Crimpers can crimp hose and fi ttings from
Direct-reading metric
virtually any manufacturer. micrometer allows for
precise adjustment of
These fully adjustable crimpers can be set to the
Removable pusher and crimp diameters
precise crimp diameter needed without the use spring-loaded die sets
of shims or spacer rings. for easy loading, even
with bent tube and
Open design provides
special fi ttings
excellent operator
visibility

D100S Standalone Crimper
works with any 10,000 psi
hydraulic pump (not included)

D100P Air-Powered Crimper
D100H Hand-Operated Crimper includes pneumatic pump
includes 2-stage manual pump and steel carrying case
and steel carrying case

Two-piece die sets allow quick, easy die changes. With Steel carrying case
an eff ective crimp range of two to four millimeters, each (D100H and D100P
only) has a storage
adjustable die set crimps a variety of hoses and fi ttings.
compartment in the
lid for dies, tools and
Dies are sold separately, so you can buy as many or as few
operator’s manual.
as you need. Recommended die selection is shown with
crimp specifi cations on pages 151
Adjustable Eff ective Adjustable Eff ective Adjustable Eff ective
Die Set Crimp Range Price Die Set Crimp Range Price Die Set Crimp Range Price
D100-07MM 7–8 mm D100-43MM 1 43–45 mm D200-35MM 35–39 mm
D100-08MM 8–10 mm D100-47MM 1 47–51 mm D200-39MM 39–43 mm
D100-10MM 10–13 mm D100-51MM 1 51–55 mm D200-43MM 43–45 mm
D100-12MM 12–15 mm D200-07MM 7–8 mm D200-47MM 47–51 mm
D100-14MM 14–17 mm D200-08MM 8–10 mm D200-51MM 51–55 mm
D100-16MM 16–20 mm D200-10MM 10–13 mm D200DA-55MM 2 55–57 mm
D100-19MM 19–23 mm D200-12MM 12–15 mm D200DA-58MM 2 58-60 mm
D100-22MM 22–26 mm D200-14MM 14–17 mm D200DA-60MM 2 60–62mm
D100-25MM 25–29 mm D200-16MM 16–20 mm D200DA-72MM 2 72-74 mm
D100-28MM 28–32 mm D200-19MM 19–23 mm D200DA-74MM 2 74-76 mm
D100-31MM 31–35 mm D200-22MM 22–26 mm
D100-35MM 35–39 mm D200-25MM 25–29 mm
D100-37MM 37–41 mm D200-28MM 28–32 mm
D100-39MM 1 39–43 mm D200-31MM 31–35 mm
(1) For use with D165 only. (2) DA double-angle dies require additional double-angle tooling (sold separately).
