Page 146 - DHH Catalog

Pressure Gauges HYDRAULIC HOSE
.com ®

Bottom-Mounted Gauges

Pressure Range Figure Interval Item # Price
0 to 15 psi 3 (.25 graduated) AFC-15-25
0 to 30 psi 5 (.5 graduated) AFC-30-25
0 to 60 psi 10 (1 graduated) AFC-60-25
0 to 100 psi 20 (2 graduated) AFC-100-25
0 to 160 psi 20 (2 graduated) AFC-160-25
0 to 300 psi 50 (4 graduated) AFC-300-25
2½" Face, Liquid-Filled 0 to 600 psi 100 (10 graduated) AFC-600-25
Pressure Gauges 0 to 1,000 psi 200 (20 graduated) AFC-1M-25

Glycerin-fi lled dual-scale (english/metric) 0 to 1,500 psi 300 (50 graduated) AFC-1500-25
stainless case, brass movement pressure 0 to 2,000 psi 400 (40 graduated) AFC-2M-25
gauges. 0 to 3,000 psi 500 (50 graduated) AFC-3M-25
• 1/4" male NPT brass connection. 0 to 5,000 psi 1,000 (100 graduated) AFC-5M-25
• Safety blow-out plug included. 0 to 6,000 psi 1,000 (100 graduated) AFC-6M-25
• Restrictors standard. 0 to 10,000 psi 2,000 (200 graduated) AFC-10M-25
• Accuracy within 2.5% of max. graduation. 0 to 15,000 psi 3,000 (300 graduated) AFC-15M-25
• Stainless steel case.
• Phosphor bronze bourdon tube. Rear-Mounted Gauges
• Brass movement with highly fi nished
bearing surface. Mounting bracket and screws (AFC-BRACKET) sold separately.

Pressure Range Figure Interval Item # Price
n/a n/a AFC-BRACKET
0 to 15 psi 3 (.25 graduated) AFC-15-25RC
0 to 30 psi 5 (.5 graduated) AFC-30-25RC
0 to 60 psi 10 (1 graduated) AFC-60-25RC
0 to 100 psi 20 (2 graduated) AFC-100-25RC
0 to 160 psi 20 (2 graduated) AFC-160-25RC
0 to 300 psi 50 (4 graduated) AFC-300-25RC
0 to 600 psi 100 (10 graduated) AFC-600-25RC
0 to 1,000 psi 200 (20 graduated) AFC-1M-25RC
0 to 1,500 psi 300 (50 graduated) AFC-1500-25RC
0 to 2,000 psi 400 (40 graduated) AFC-2M-25RC
0 to 3,000 psi 500 (50 graduated) AFC-3M-25RC
0 to 5,000 psi 1,000 (100 graduated) AFC-5M-25RC
0 to 6,000 psi 1,000 (100 graduated) AFC-6M-25RC
0 to 10,000 psi 2,000 (200 graduated) AFC-10M-25RC
0 to 15,000 psi 3,000 (300 graduated) AFC-15M-25RC

Rear-Mounted Gauges available with
Mounting Bracket and Screws
(sold separately)

Item #: AFC-BRACKET
