CM Series Valved Couplers
Industrial Mold Coolant
Interchange

Item # Material Body Thread Price
2CMF1-B Brass 1/4" 1/8" NPT (female)
3CMF2-B Brass 3/8" 1/4" NPT (female)

Unvalved Couplers
Item # Material Body Thread Price
2CMF1-B-E Brass 1/4" 1/8" NPT (female)
3CMF2-B-E Brass 3/8" 1/4" NPT (female)
Interchanges with: 4CMF4-B-E Brass 1/2" 1/2" NPT (female)
• Foster Series FJT
• Hansen Flo-Temp Nipples (NPT female)
• Tomco Series MC
• Parker Moldmate
Designed for use with industrial mold applications.
Slender profi le is ideal installation and operation in Item # Material Body Thread Price
tight spaces. CM2F1-B Brass 1/4" 1/8" NPT (female)
• Silicone sealing gaskets (standard) optimize CM2F2-B Brass 1/4" 1/4" NPT (female)
performance in coolant applications CM2F3-B Brass 1/4" 3/8" NPT (female)
• Temperature range: -90° to 400° F CM3F2-B Brass 3/8" 1/4" NPT (female)
• Highly durable and corrosion-resistant materials
for maximum longevity and performance CM3F3-B Brass 3/8" 3/8" NPT (female)
• Valved couplers provide automatic shut-off upon CM4F4-B Brass 1/2" 1/2" NPT (female)
disconnection to avoid fl uid loss. CM4F6-B Brass 1/2" 3/4" NPT (female)
• Non-valved straight-thru couplers are available to CM2F1 Steel 1/4" 1/8" NPT (female)
maximize fl ow performance. CM2F2 Steel 1/4" 1/4" NPT (female)
CM2F3 Steel 1/4" 3/8" NPT (female)
Recommended Valved
Body Operating Unvalved Flow Flow Rate CM3F2 Steel 3/8" 1/4" NPT (female)
Size Pressue (psi) Rate (gpm) (gpm) CM3F3 Steel 3/8" 3/8" NPT (female)
1/4" 200 6 3.5
Nipples (NPT male)
3/8" 200 13 7
1/2" 200 35 20

Item # Material Body Thread Price
CM2M1-B Brass 1/4" 1/8" NPT (male)
CM2M2-B Brass 1/4" 1/4" NPT (male)
CM2M3-B Brass 1/4" 3/8" NPT (male)
CM3M2-B Brass 3/8" 1/4" NPT (male)
CM3M3-B Brass 3/8" 3/8" NPT (male)
CM3M4-B Brass 3/8" 1/2" NPT (male)
CM4M4-B Brass 1/2" 1/2" NPT (male)
CM4M6-B Brass 1/2" 3/4" NPT (male)
