71 Series Couplers
Flushface / Dry Break Coupling Item # Description Thread Material Price
71-3C-04-04F 1/4" Coupler 1/4" NPT (female) Steel
71-3C-06-06F 3/8" Coupler 3/8" NPT (female) Steel
71-3C-08-08F 1/2" Coupler 1/2" NPT (female) Steel
71-3C-12-12F 3/4" Coupler 3/4" NPT (female) Steel
71-3C-16-16F 1"Coupler 1" NPT (female) Steel
71-3C-16-20F 1" Coupler 1¼" NPT (female) Steel

Nipples
Interchanges with: Item # Description Thread Material Price
• Snap-Tite 71 Series 71-3N-04-04F 1/4" Nipple 1/4" NPT (female) Steel
71-3N-06-06F 3/8" Nipple 3/8" NPT (female) Steel
Ideal for test stands and other chemical and
hydraulic applications where endurance and 71-3N-08-08F 1/2" Nipple 1/2" NPT (female) Steel
cleanliness are requirements. Air inclusion and fl uid 71-3N-12-12F 3/4" Nipple 3/4" NPT (female) Steel
loss are held to a minim to prevent spillage and 71-3N-16-16F 1" Nipple 1" NPT (female) Steel
contamination of systems. 71-3N-16-20F 1" Nipple 1¼" NPT (female) Steel
• Push to connect, simply insert nipple into coupler
• Retract sleeve to disconnect Elastomer Dust Plugs and Caps
• Ideal for high impulse applications
Item # Description Price
71-3PCC-04 Dust Plug for 1/4" Coupler
Maximum
Working Maximum 71-3PNC-04 Dust Cap for 1/4" Nipple
Body Pressure Flow Rate 71-3PCC-06 Dust Plug for 3/8" Coupler
Size (psi) (gpm)
71-3PNC-06 Dust Cap for 3/8" Nipple
1/4" 10,000 5
71-3PCC-08 Dust Plug for 1/2" Coupler
3/8" 10,000 13
71-3PNC-08 Dust Cap for 1/2" Nipple
1/2" 10,000 22
71-3PCC-12 Dust Plug for 3/4" Coupler
3/4" 7,500 42
71-3PNC-12 Dust Cap for 3/4" Nipple
1" 7,500 58
71-3PCC-16 Dust Plug for 1" Coupler
71-3PNC-16 Dust Cap for 1" Nipple
